Product Summary
The TLP627 is a GaAs IRED & photo-transistor. The TLP627 consists of a gallium arsenide infrared emitting diode optically coupled to a darlington connected phototransistor which has an integral base-emitter resistor to optimize switching speed and elevated temperature characteristics. The TLP627 offers two isolated channels in a eight lead plastic DIP. Applications are (1)programmable controllers; (2)DC-output module; (3)telecommunication.
Parametrics
TLP627 absolute maximum ratings: (1)Forward Current IF: 60mA; (2)Power Dissipation (1 Circuit)PD: 100mW; (3)Reverse Voltage VR: 5 V; (4)Junction Temperature Tj: 125 °C; (5)Collector-Emitter Voltage VCEO: 300 V; (6)Emitter -Collector Voltage VECO: 0.3 V; (7)Collector Current IC: 150 mA; (8)Collector Power Dissipation (1 Circuit)PC 150(*300): 100 mW; (9)Junction Temperature Tj: 125 °C; (10)Operating Temperature Range Topr: -55~100 °C; (11)Storage Temperature Range Tstg: -55~125 °C; (12)Lead Soldering Temperature (10s)Tsold: 260(10sec)°C; (13)Total Package Power Dissipation PT: 250mW; (14)Isolation Voltage (AC,1min. , R.H.≤60%)(Note1)BVS: 5000 Vrms.
Features
TLP627 features: (1)Collector-Emitter Voltage : 300V(Min); (2)Current Transfer Ratio : 1000%(Min); (3)Isolation Voltage : 5000Vrms(Min); (4)UL Recognized : UL1577,File No.E67349.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TLP627 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
TLP627(F) |
Toshiba |
Transistor Output Optocouplers 300V Photocoupler 5000 Vrms 150 IC |
Data Sheet |
|
|
||||||||||||
|
TLP627(F,T |
Toshiba |
Transistor Output Optocouplers INCORRECT MOUSER P/N |
Data Sheet |
Negotiable |
|
||||||||||||
|
TLP627(F,T) |
Toshiba |
Transistor Output Optocouplers 300Vceo 5000Vrms |
Data Sheet |
|
|
||||||||||||
|
TLP627(TP1) |
|
PHOTOCOUPLER DARL TRANS-OUT 4SMD |
Data Sheet |
Negotiable |
|
||||||||||||
|
TLP627(TP1,F) |
Toshiba |
Transistor Output Optocouplers 300V Phototransistor 5000 Vrms 60 IF |
Data Sheet |
|
|
||||||||||||
|
TLP627(TP1,F,T) |
Toshiba |
Transistor Output Optocouplers DARL. HI Vceo (300Vmin) |
Data Sheet |
Negotiable |
|
||||||||||||
|
TLP627(TP1,T) |
|
PHOTOCOUPLER DARL TRANS-OUT 4SMD |
Data Sheet |
Negotiable |
|
||||||||||||
